Infiray IRIS IL19
Thermal Imaging Monocular IRIS Series - IL19
The Iris Series will surprise you with its exceptional image quality, which is significantly better than average, and its ultimate portable size, even smaller than a mobile phone. The lightweight design of 330g, IP67 waterproof rating and replaceable 18650 battery make it your most portable and reliable thermal spotter.
Reality+ image enhancement algorithms
The latest Reality+ image enhancement algorithms can effectively improve image quality and remove noise, bringing out the full potential of the thermal sensor.
The F0.9 lens provides 20% more light range compared to a normal F1.0 lens, generating brighter and clearer images.
The self-developed sensor delivers stable and excellent performance, with a NETD＜20mK, ensuring superior images under harsh conditions.
The ultra-silent buttons ensure that you do not disturb your prey during use.
The Iris is equipped with various color palettes, including the red and green palette, which are designed to prevent eye fatigue, allowing for comfortable long-term use is.
The Iris is equipped with the best replaceable 18650 battery, which allows up to 5 hours of continuous use per charge.
The eyepiece with an exit pupil diameter of 10 mm ensures the best viewing angle and visibility in every angle and situation.
| Resolution，pixels | 384×288 |
| Pixel, μm | 12 |
| NETD, mK | ＜20 |
| Frame Rate, Hz | 50 |
| Optical Specifications |
| Objective Lens, mm | 19 F0.9 |
| Field of View (H×V), º | 13.8×10.4 |
| Linear Field of View (H×V), m at 100m | 24×18 |
| Magnification, × | 2~8 |
Detective Range, m
(Target size: 1.7m × 0.5m, P(n)=99%) | 980 |
| Exit Relief, mm | 25 |
| Exit Pupil Diameter, mm | 10 |
| Diopter, D | -5 ~ +5 |
| Display Specifications |
| Type | AMOLED |
| Resolution, pixels | 1024×768 |
| Battery Power Supply |
| Battery | Replaceable Li-ion battery 18650 / 3200mAh |
| Max. Operation Time, (t=22℃) h★ | 5 |
| Physical Specifications |
| MIC | Support |
| Memory Capacity, GB | 32 |
| IP Rating | IP67 |
| Operating Temperature, ºC | -20 ~ +50 |
| Weight, g | ≤330 |
| Dimension, mm | ≤143×47×74 |
Quick start guide
