Pulsar Thermion 2 XG50
The Thermion 2 XG50 is an evolution of Pulsar's renowned line of digital riflescopes. Equipped with a sensitive <40 NETD 12 µm pixel pitch sensor, it delivers a sharp 640x480 resolution and provides the sharpness needed to capture potentials in densely forested areas. A 1024 x 768 AMOLED display allows users to observe the world around them in stunning clarity. It is equipped with a fast F50 F/1.0 lens and has a base magnification of 3x, with digital zoom capabilities up to 24x.
With an impressive detection range of 2,500 meters, this scope matches the capabilities of long-range precision rifles. The zero settings can be conveniently saved in the shooting profiles, with the Thermion 2 offering up to five profiles for different weapons or cartridges. Each profile can contain data for ten zeroing distances.
A single charge of the Thermion 2 XG50's dual battery system provides up to 10 hours of battery life, enough for extended hunting trips. This indirect digital domain riflescope also includes an actual video recorder with 16 GB of storage and Wi-Fi compatibility via Stream Vision 2. This feature allows users to stream the riflescope's video feed to their mobile devices.
Designed with durability in mind, the Thermion 2 It is suitable for use with a wide range of firearms, including rifled hunting weapons in calibers such as .30-06, 300, 375H&H, as well as smoothbore weapons such as shotguns and shotguns.
muzzleloaders and pneumatic air weapons.
The Thermion 2 LRF riflescopes are designed to operate effectively in extreme temperatures, from -13 to +122°F. The frost-resistant AMOLED display ensures a fast response time and improves image sharpness, even when observing moving targets.
Features
High-Definition heating sensor (640x480 pixels @ 12 µm) Heating sensor sensitivity <40 mK NETD
Large aperture lens F50/1.0
Large detection range up to more than 2500 meters Variable magnification
built-in photo and video recorder
Up to 9 hours of battery life on a single charge 10 reticle shapes in 9 color modes
8 color palettes
Standard 30mm mounting rings IPX7 Completely waterproof
Enhanced Wi-Fi connectivity with support for 2.5/5 GHz waveband. Stream Vision 2 app is supported
Specifications
Main |
Sensor | 640x480 @ 12 µm (NETD <40 mK) |
Objective lens | F50 / 1.0 |
Magnification, x | 3 – 24 |
Field of view (HxV), degrees / m@100m | 8.8x6.6 / 15.4x11.5 |
Detection range, m | 2300 |
Sensor |
Type | uncooled |
Resolution, pixels | 640x480 |
Pixel pitch, µm | 12 |
NETD, mK | 40 |
Frame rate, Hz | 50 |
Optics |
Objective lens | F50 / 1.0 |
Magnification, x | 3 – 24 |
Field of view (HxV), degrees / m @ 100 m | 8.8x6.6 / 15.4x11.5 |
Eye relief, mm | 50 |
Display |
Type | AMOLED |
Resolution, pixels | 1024х768 |
Range Performance |
Detection range, m | 2300 |
Laser Rangefinder |
Safety class for laser equipment according to IEC 60825-1:2014 | - |
Wavelength, nm | - |
Max. measuring range, m | - |
Measurement accuracy, m | - |
Reticle |
Click value, H/V, mm at 100 m | 15 – 3х, 7.5 – 6х, 3.75 – 12х, 1.86 – 24х |
Click range, H/V, mm at 100 m | 3000 / 3000 |
Number of preloaded reticles | 10 |
Video Recorder |
Video / photo resolution, pixel | 1024x768 |
Video / photo format | .mp4 / .jpg |
Built-in memory, GB | 16 |
Wi-Fi |
Wireless Protocol | Wi-Fi |
Wireless Standard | IEEE 802.11 b/g/n/ac (WPA) |
Frequency, GHz | 2.4 / 5 |
Bluetooth |
Wireless Protocol | - |
Wireless Standard | - |
Frequency, GHz | - |
Environmental Characteristics |
Degree of protection, IP code (IEC60529) | IPX7 |
Operating temperature range, °С | -25 – +50 |
Connections and Compatibilities |
Max. recoil power on rifled weapon (Eo), Joules | 6000 |
Shock resistance on the smooth-bore rifles, caliber | 12 |
Compatible mounts | Standard 30mm rings |
Supported Application | Stream Vision 2 |
Power Supply |
Output voltage, V | 3.7 |
Battery type | Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal) |
Capacity, mAh | 2000 (external) + 4900 (internal) |
Operating time on battery pack (at t=22°C), h * | 9 |
External power supply, V | 5V, 9V (USB Type-C Power Delivery) |
Weight & Size |
Body material | Aluminum alloy |
Dimensions, mm | 412x78x83 |
Weight, kg | 0.9 |
Trade Data |
SKU (Model #) | 76549 |
Status | production |
