Pulsar Digex X850S IR
Interchangeable infrared illuminators for Digex digital night vision riflescopes. Smooth power adjustment.
Adjustable IR spot position.
Mounting diameter 30 mm.
Field of view (HxV), degrees / m @ 100 m
Infrared Illuminator
Emitter
LED
IR wavelength, nm
850 (long-range)
IR Optical power, mW
up to 800m
-
Environmental Characteristics
Degree of protection, IP code (IEC60529)
-
Operating temperature range, °С
-25 – +50
Connections and Compatibilities
Max. recoil power on rifled weapon (Eo), Joules
6000
Shock resistance on the smooth-bore rifles, caliber
12
Related Products
Digex N450 / N455
Mount, type
quick-release 30 mm ring
Length of mounting part, mm
-
Distance between the centers of locking screws, mm
-
Additional information
-
Lens Diameter of daylight device, mm
-
Internal diameters of the included insert rings, mm
-
Power Supply
Output voltage, V
3.0 - 4.2
Battery type
Li-Ion Battery Pack APS2
Capacity, mAh
2000
Operating time on battery pack (at t=22°C), h *
7
Weight & Size
Body material
-
Total length, mm
-
Dimensions, mm
129x84x75
Weight, kg
0.14
Trade Data
SKU (Model #)
79077
Status
-
