Powerful Thermal Riflescope with Ballistic Calculator and Laser Rangefinder
The Pulsar Trail 3 LRF XR50 is a professional thermal imaging riflescope featuring a highly sensitive 640x480 12μm VOx sensor and a bright 1920x1080 AMOLED display. It offers an impressive detection range of up to 2300 meters and an integrated laser rangefinder up to 1200 meters with ±1 meter accuracy. With stepless digital zoom (3x–24x), recoil-activated video recording, an advanced ballistic calculator, and Bluetooth/Wi-Fi connectivity, this model is ideal for demanding hunters and professionals. The durable magnesium alloy monoblock housing and the replaceable LPS7i battery with up to 11 hours runtime make the Trail 3 LRF XR50 highly suitable for long-term use under tough conditions, including high-recoil calibers up to .375 H&H.
Key Features
- 640x480 12μm sensor with NETD <18 mK
High sensitivity and contrast – reliable detection even in rain, fog, or low temperatures. - Magnesium alloy monoblock housing
Extremely rugged and recoil-resistant up to 6000 Joules – ideal for large calibers. - Laser rangefinder up to 1200 meters
Accurate distance measurement in single or scan mode with ±1 meter precision. - Integrated ballistic calculator
Automatic aiming corrections based on your ballistic profile. - Recoil-activated video recording & 64GB internal memory
Automatically records when firing – never miss a crucial moment. - Full HD AMOLED display (1920x1080)
High-resolution image with natural colors – comfortable for long viewing sessions. - Round Picture-in-Picture view
Enlarges the target area without losing your full field of view – perfect for moving targets. - Stepless digital zoom & advanced zeroing tools
Easy sighting with freeze, zoom, and one-shot zeroing functions. - Bluetooth, Wi-Fi & Stream Vision 2 compatible
Connect to your smartphone for control, updates, and media sharing. - Quick-switch LPS7i battery (up to 11 hours)
Long operating time and easy to swap – perfect for extended use in the field.
Video Pulsar Trail 3 LRF XR50
Included Accessories
- Quick-switch LPS7i battery (6400 mAh)
- USB Type-C cable with adapter
- Rubber eyecup
- Power adapter
- Lens cleaning cloth
- Carrying case
- Quick Start Guide
- SV Ballistics Quick Start Guide
- Warranty card
- *Mount and screws optional depending on model configuration
Main Specifications Pulsar Trail 3 LRF XR50
| Model | Trail 3 LRF XR50 |
| Resolution and μm | 640x480 / 12μm |
| Sensor type | VOx uncooled microbolometer |
| NETD | <30 mK / <18 mK |
| Detection range | 2300 meters |
| Rangefinder | Yes |
| Lens diameter | F50 / 1.0 |
| Field of View | 8.8° / 15.4m @100m |
| Screen type | AMOLED HD 1920x1080 |
| Battery duration | Up to 11 hours |
| Battery replaceable | Yes |
| Weight | 700 grams (without mount) |
| Color Palettes | 9 (e.g. Whitehot, Blackhot, Rainbow) |
| Zoom options | Stepless via 180° encoder |
| Adjustable contrast | Yes |
| Water-resistance rating | IP67 |
Availability and Demonstration
The Pulsar Trail 3 LRF XR50 is available for demonstration by appointment. Our team of experienced hunters is happy to provide you with expert advice and a hands-on introduction to this high-end model.
Additional Technical Specifications
- 3 sensitivity levels: Normal / High / Ultra-High
- 3 calibration modes: Auto / Semi / Manual
- Noise reduction via smoothing filter
- Proximity sensor for automatic screen deactivation
- Image shapes: round, rectangular, oval
- 10 reticle types and 11 color options
- Zeroing tools: Freeze, Zoom, One-Shot
- Diopter adjustment: -5 / +5
- Bluetooth BLE 4.2 & Wi-Fi 2.4 / 5 GHz
- Video output via USB-C – video resolution: 1440x1080 (.mp4 / .jpg)
- Compatible with Stream Vision 2 & Ballistics app
- Dimensions: 271x86x71 mm
