Flagship thermal imaging riflescope with 1280×1024 sensor and 3,100 metre detection range
The Nocpix ACE 2 S60R is the flagship model in the ACE 2 series and combines an exceptionally high 1280×1024 thermal imaging resolution with a 12 μm VOx sensor, NETD ≤12 mK and a large 60 mm F1.0 lens. With a detection range of up to 3,100 metres and a wide field of view of 25.6 × 20.5 metres at 100 metres, this thermal imaging riflescope offers a high level of detail and excellent situational awareness for observation and hunting.
The S60R features Dual Clarity, allowing you to choose between Motion for a smoother image of moving targets and Still for improved assessment of fine details. In addition, Ocular Zoom 2.0, R+ 2.0 image processing, the integrated LRF 2.0 up to 1,200 metres and Ballistic Calculation 2.0 provide a comprehensive combination of observation, rangefinding and aiming support. The 30/60 Hz frame rate ensures a smooth thermal image.
Nocpix Ace 2
10 key features of the Nocpix ACE 2 S60R
- 1280×1024 / 12 μm VOx sensor: the high thermal resolution makes small details clearly visible and supports precise assessment of the thermal image.
- NETD ≤12 mK: high thermal sensitivity makes small temperature differences visible, even in fog, rain and conditions with low thermal contrast.
- 60 mm F1.0 lens: the large and fast lens is designed for strong thermal performance and long-distance observation.
- Detection range up to 3,100 metres: provides an exceptionally long observation range and is the highest stated detection range within the ACE 2 series.
- Dual Clarity Motion & Still: choose Motion for a smoother image when tracking movement or Still to assess fine details more clearly.
- Ocular Zoom 2.0: combines optical and digital magnification for comfortable zooming while maintaining a natural viewing experience.
- Integrated LRF 2.0 up to 1,200 metres: measures distance quickly and accurately with a stated accuracy of ±1 metre.
- R+ 2.0 image algorithm: advanced image processing improves detail and reduces image noise for a clearer thermal image.
- Ballistic Calculation 2.0: processes data including distance and angle to calculate additional ballistic information and a suitable aiming point.
- 980 gram magnesium housing: combines a large 1280 sensor and 60 mm lens with a robust construction while keeping the total weight below 1 kilogram.
Included with the Nocpix ACE 2 S60R
- Heated target for zeroing
- Lens cleaning cloth
- Quick start guide
- Type-C cable
- 2× 18650 batteries
- 2× rubber grips for the focus control
- Battery charger
- Carry bag
Main specifications Nocpix ACE 2 S60R
| Model | ACE 2 S60R |
| Resolution and μm | 1280×1024, 12 μm |
| Sensor type | VOx uncooled thermal sensor |
| NETD | ≤12 mK |
| Detection range | Up to 3,100 metres |
| Rangefinder | Yes, integrated LRF 2.0 up to 1,200 metres, accuracy ±1 metre |
| Lens diameter | 60 mm F1.0 |
| Field of View | 14.7° × 11.7° / 25.6 × 20.5 metres at 100 metres |
| Display type | AMOLED 2560×2560 |
| Battery life | Up to 7 hours at 22 °C |
| Battery replaceable | Yes, replaceable 18650 battery in addition to the built-in 3650 mAh battery |
| Weight | 980 grams |
| Colour palettes | White Hot / Black Hot / Red Hot / Rainbow / Violet / Crimson / Viridian |
| Zoom options | Ocular Zoom 2.0, optical 2 to 4×, up to 28× according to the manual |
| Adjustable contrast | Yes, 10 levels |
| Water resistance | IP67 |
Additional manufacturer specifications
The Nocpix ACE 2 S60R has a frame rate of 30/60 Hz, an eye relief of 60 mm, an exit pupil of 10 mm and a dioptre adjustment range of -5 to +4. The Dual Clarity function available on this model provides separate Motion and Still modes for different observation situations.
For storing images and recordings, the riflescope features 64 GB of internal memory. Photo and video recording are supported, together with Recoil Activated Video and an integrated gallery. Wi-Fi and app support provide additional connectivity and functions with a mobile device.
The S60R also features Picture-in-Picture, a built-in compass, motion sensor, tracking, pixel correction and various calibration modes. Display brightness, sharpness and contrast can each be adjusted across ten levels.
The dimensions are 397 × 73 × 92 mm. The stated operating temperature range is -20 °C to +50 °C. The magnesium housing meets the IP67 rating and the riflescope is rated for a maximum recoil energy of 7,000 joules.
View and test the Nocpix ACE 2 S60R at JVS Outdoor
The Nocpix ACE 2 S60R is available to view and test by appointment at JVS Outdoor. You can compare the different models in the ACE 2 series and receive advice from experienced hunters on which version best suits your intended use and preferred shooting distance.
