Pulsar Telos LRF XT50 with 1280x1024 HD Sensor and Integrated Laser Rangefinder
The Pulsar Telos LRF XT50 is the flagship of the upgradeable Telos series and combines a high-quality 1280x1024 pixel 12 μm thermal sensor with a 50 mm F1.0 objective lens and an integrated laser rangefinder with a measuring range of up to 1200 metres. Thanks to its wide 17.5° field of view and detection range of up to 2300 metres, this thermal imaging monocular is particularly suitable for observation and hunting in open terrain, along forest edges and in mixed landscapes.
Video Pulsar Telos LRF XT50
The high sensor resolution is not only designed to detect heat sources at long distances. The Telos LRF XT50 is built to retain as much detail as possible in the thermal image after the initial detection. This makes it easier to assess shapes, movements and characteristics of different animals at longer distances instead of seeing only a general heat signature.
The wide field of view makes it easier to scan large areas quickly. Once a heat source has been detected, the Full HD AMOLED display and electronic image stabilization provide a stable and detailed image, even when using higher magnification. The integrated laser rangefinder can then be used to determine the distance to the observed object directly, without requiring a separate device.
The Telos LRF XT50 features an ergonomic, rubber-coated housing for a secure grip in wet or cold conditions. The main controls are positioned on top of the device. The focus and zoom rings feature a clearly textured surface, making adjustments easier even with cold hands or while wearing gloves. Gold-coloured accents around the objective lens further emphasize the XT50's position as the flagship model within the Telos series.
The replaceable LPS7i battery provides up to 8 hours of operating time and supports USB Type-C Power Delivery as well as wireless charging. With 128 GB of internal storage, Wi-Fi, Bluetooth, NFC and Stream Vision 2 support, the Telos LRF XT50 also offers extensive options for recording, transferring and managing images and videos.
Key Features of the Pulsar Telos LRF XT50
- 1280x1024 HD thermal sensor
The 12 μm sensor provides very high thermal resolution, allowing small details and subtle temperature differences to remain visible. This not only helps with detecting game, but especially with assessing animals more accurately after the initial detection. - Detection range up to 2300 metres
The long detection range makes the Telos LRF XT50 ideal for quickly locating game and other heat sources over large distances. - Integrated laser rangefinder up to 1200 metres
Distances can be measured with an accuracy of ±1 metre in both single measurement and scan mode. This allows you to check the distance immediately without having to use a separate rangefinder. - Wide 17.5° field of view
A linear field of view of 30.7 metres at 100 metres makes it possible to cover larger areas at once. This reduces the amount of sweeping required when scanning an area for game. - 2x to 16x magnification with Zoom Boost up to 24x
Smooth digital magnification is controlled using the zoom ring around the objective lens. The pronounced texture of the focus and zoom rings makes operation easier with cold hands or gloves. - Electronic image stabilization
Image stabilization reduces visible movement caused by hand shake. This provides a steadier image during extended observation and makes fine details easier to assess at higher magnification. - Full HD AMOLED display
The 1920x1080 AMOLED display presents the thermal image with excellent sharpness and contrast. Combined with image stabilization, the device is particularly suitable for extended observation and detailed viewing of distant heat sources. - Replaceable LPS7i battery with flexible charging options
The 6400 mAh Li-Ion battery provides up to 8 hours of operating time and supports USB Type-C Power Delivery, charging via a power bank and wireless Qi charging. - 128 GB internal storage and extensive connectivity
Record photos and videos with sound and connect the thermal imaging device to compatible apps and devices using 2.4 GHz or 5 GHz Wi-Fi, Bluetooth and NFC. - Robust flagship design
The rubber-coated housing, IPX7 waterproof rating and operating temperature range from -25°C to +40°C make the Telos LRF XT50 suitable for intensive use. Gold-coloured details visually distinguish the XT50 from other models in the Telos series.
What Is Included with the Pulsar Telos LRF XT50?
- Pulsar Telos LRF XT50 thermal imaging monocular
- LPS7i Li-Ion battery with protective cover
- Spare battery compartment cover
- Power adapter
- USB Type-C cable with USB Type-A adapter
- Carrying case
- Hand strap
- Quick Start Guide
- Lens cleaning cloth
- Warranty card
Key Specifications Pulsar Telos LRF XT50
| Model | Pulsar Telos LRF XT50 |
| Resolution and μm | 1280x1024 pixels, 12 μm |
| Sensor type | Uncooled microbolometer |
| NETD | Sensor NETD <40 mK, System NETD <20 mK |
| Detection range | Up to 2300 metres for deer-sized objects |
| Rangefinder | Yes, laser rangefinder up to 1200 metres, accuracy ±1 metre |
| Objective lens | 50 mm F1.0 |
| Field of View | 17.5° x 14°, 30.7 metres at 100 metres |
| Display type | AMOLED HD, 1920x1080 pixels |
| Battery life | Up to 8 hours at 22°C |
| Replaceable battery | Yes, LPS7i Li-Ion 6400 mAh |
| Weight | 730 grams including battery |
| Colour palettes | White Hot / Black Hot / Green / Red Hot / Red Monochrome / Rainbow / Ultramarine / Violet / Sepia |
| Zoom options | 2x to 16x, up to 24x with Zoom Boost |
| Adjustable contrast | Yes, adjustable from 0 to 20 |
| Water resistance | IPX7 |
Search, Identify and Measure Distance with One Device
The Pulsar Telos LRF XT50 is particularly designed for the part of the hunt that takes place before a decision is made. The wide field of view allows open terrain and large areas to be scanned quickly. Once a heat source has been detected, the high sensor resolution, Full HD display and electronic image stabilization help you examine the object in greater detail.
This allows the XT50 to combine several important tasks in one thermal imaging monocular. You can scan an area, detect a heat source, observe the animal at higher magnification and then use the integrated laser rangefinder to determine the distance directly. This reduces the need to switch continuously between different devices during observation.
Additional Features of the Pulsar Telos LRF XT50
Frame rate: 50 Hz
Optical magnification: 2x
Digital zoom: 1x to 8x, with Zoom Boost up to 12x digital zoom
Total magnification: 2x to 16x, with Zoom Boost up to 24x
Minimum focusing distance: 5 metres
Diopter adjustment: -5 to +4 dpt
Eye relief: 13 mm
Photo and video resolution: 1440x1080 pixels
File formats: MP4 video and JPG photo
Internal storage: 128 GB
Video with sound: Yes, integrated microphone and video recorder
Wi-Fi: 2.4 GHz and 5 GHz, IEEE 802.11 b/g/n/ac
Bluetooth: BLE 5.0
NFC: Yes, for quick pairing with Stream Vision 2
Supported apps: Stream Vision 2 and Stream Vision Ballistics
Ballistic calculator: Yes
Picture-in-Picture: Yes
Image stabilization: Yes
Calibration modes: Manual, semi-automatic and automatic
Sensitivity levels: Normal, High and Ultra
Image filter: Smoothing Filter for reducing digital image distortion
Display functions: Display Dimming, Display Off and automatic display shut-off
Haptic feedback: Yes, vibration feedback through the control buttons
USB connection: USB Type-C with support for external power and Power Delivery
External power supply: 5 V or 9 V via USB Type-C
Operating temperature: -25°C to +40°C
Dimensions: 242 x 72 x 77 mm
Tripod connection: 1/4 inch
Laser: 905 nm, safety class 1
SKU: 77524
Upgradeable Telos Platform
The Telos series has been developed around Pulsar's upgrade concept. This means that certain important hardware components can be renewed through the official Telos Upgradeability service when new compatible technologies become available. Pulsar lists sensor upgrades and objective lens upgrades among the possible options within this concept.
This makes the Telos series a platform designed to keep pace with technological developments for longer. The XT50 currently represents the flagship of this upgradeable product line.
Stream Vision 2 and Wireless Connectivity
The Pulsar Telos LRF XT50 can be connected to a compatible iOS or Android smartphone using the Stream Vision 2 app. This allows you to view stored photos and videos, stream live images, manage files and perform firmware updates.
Support for both 2.4 GHz and 5 GHz Wi-Fi allows you to select the preferred wireless connection depending on the conditions. NFC makes pairing with a compatible smartphone easier, while Bluetooth is used for compatible functions within the Pulsar ecosystem.
Designed for Intensive Observation
The symmetrical arrangement of the controls makes the Telos LRF XT50 suitable for both left-handed and right-handed use. The main control buttons are positioned on top of the housing, keeping them easily accessible during observation.
The focus and zoom rings are positioned directly around the objective lens. Their more pronounced texture makes it easier to adjust settings by touch, for example when wearing gloves or when your hands are cold.
The rubber-coated housing provides additional grip in dry, wet and cold weather. Combined with its IPX7 waterproof rating and wide operating temperature range, the Telos LRF XT50 is designed for demanding observation and hunting conditions.
View the Pulsar Telos LRF XT50 at JVS Outdoor
The Pulsar Telos LRF XT50 is available to view and try at JVS Outdoor by appointment. Our advisors are experienced hunters themselves and can help you compare thermal imaging devices and select a model that suits your hunting area, required detection range and style of observation.
