Hikmicro Habrok 4K 2.0 thermal imaging, 4K day and night vision and 1000 metre laser rangefinder
The HIKMICRO HABROK 4K 2.0 HH35L combines thermal imaging, 4K digital day and night vision and a laser rangefinder in one multispectrum binocular. The 384 × 288 12 μm thermal sensor with a NETD of <15 mK and 35 mm F1.0 objective lens provides a detection range of up to 1,800 metres, making it easy to quickly locate game.
The digital mode offers a 3840 × 2160 4K resolution and can be used in complete darkness with the interchangeable 850 nm or 940 nm IR illuminator. The HH35L 2.0 also features HSIS shutterless technology, electronic image stabilisation, Quick-Switch and an integrated laser rangefinder with a range of up to 1,000 metres. This allows you to locate game, observe it in detail and determine the distance directly.
10 key features of the HIKMICRO HABROK 4K 2.0 HH35L
- 384 × 288 12 μm thermal sensor: provides a clear thermal image and makes it easier to quickly locate game.
- NETD <15 mK: detects small temperature differences, helping you distinguish game and surrounding details more clearly.
- 35 mm F1.0 thermal objective lens: provides a practical balance between magnification, image detail and observation range.
- Detection range up to 1,800 metres: allows game to be detected from long distances.
- 4K 3840 × 2160 day and night vision: provides a detailed digital image for observing game during the day, at dusk and at night.
- Interchangeable 850 nm and 940 nm IR illuminators: allow game to be observed even in complete darkness.
- Laser rangefinder up to 1,000 metres: quickly measures the distance to the observed game.
- HSIS shutterless technology: provides a virtually uninterrupted thermal image when searching for and tracking game.
- Electronic image stabilisation: reduces visible movement in both thermal mode and digital mode for more comfortable observation.
- Quick-Switch and central focusing: make it easy to quickly switch between thermal and digital modes and bring game into sharp focus.
What's included?
The HIKMICRO HABROK 4K 2.0 HH35L comes with the essential accessories required to start using the device.
- HIKMICRO HABROK 4K 2.0 HH35L
- 4 batteries
- Neck strap
- Tripod adapter
- Battery charger
- USB Type-C cable
- Lint-free cloth
- Removable IR illuminator
- Quick start guide
Key specifications HIKMICRO HABROK 4K 2.0 HH35L
| Model | HABROK 4K 2.0 HH35L |
| Resolution and μm | 384 × 288, 12 μm |
| Sensor type | Uncooled VOx focal plane array |
| NETD | <15 mK |
| Detection range | Up to 1,800 metres |
| Rangefinder | Yes, laser rangefinder up to 1,000 metres |
| Objective lens | 35 mm F1.0 thermal / 60 mm F2.2 digital |
| Field of view | Thermal: 7.53° × 5.65° / 13.16 × 9.87 metres at 100 metres |
| Display | 0.49 inch OLED, 1920 × 1080 |
| Battery life | ≥6.5 hours at 25°C with hotspot and LRF enabled |
| Replaceable battery | Yes, replaceable and rechargeable Li-ion batteries |
| Weight | Approx. 900 grams without batteries |
| Colour palettes | Black Hot / White Hot / Red Hot / Red Monochrome / Green Monochrome / Fusion |
| Zoom options | Thermal 4.0× to 20.0× / digital zoom steps 2× / 3× / 4× / 5× |
| Adjustable contrast | Yes |
| Water resistance | IP67 |
4K digital day and night vision
In digital mode, the HIKMICRO HABROK 4K 2.0 HH35L uses a 1/1.8 inch Progressive Scan CMOS sensor with a resolution of 3840 × 2160 pixels. The 60 mm F2.2 objective lens provides an optical base magnification of approximately 5.5× and a maximum magnification of up to 22×. This allows you to observe game in detail and distinguish important characteristics more clearly. The digital field of view is 7.3° × 4.1°, equivalent to approximately 12.8 × 7.2 metres at 100 metres.
For observing game in complete darkness, the device supports interchangeable 850 nm and 940 nm IR illuminators. The specified digital night vision range is up to 400 metres.
Laser rangefinder up to 1,000 metres
The integrated laser rangefinder uses a 905 nm Class 1 laser and has a maximum measuring range of 1,000 metres. The specified measuring accuracy is ±1 metre, with a minimum measuring distance of 10 metres. This allows you to determine the distance to observed game directly while viewing.
HSIS shutterless thermal imaging
The HABROK 4K 2.0 HH35L features HSIS, HIKMICRO Shutterless Image System. With conventional thermal imaging devices, the image can briefly pause during calibration. HSIS is designed to provide a virtually continuous thermal image. This is particularly useful when searching for and following moving game.
Electronic image stabilisation and Quick-Switch
Electronic image stabilisation is available in both thermal mode and digital mode, helping to reduce small movements during handheld observation. Quick-Switch allows you to rapidly switch between both modes, while central focusing helps bring observed game precisely into focus.
Further features and specifications
The HIKMICRO HABROK 4K 2.0 HH35L also features photo and video recording, audio recording, 64 GB internal storage, Picture-in-Picture, hotspot/Wi-Fi, Hot Track, a digital compass and a local album. The device can be connected to a compatible smartphone using the HIKMICRO Sight app.
The housing has an IP67 rating and is designed for use at temperatures from approximately -30°C to +55°C. Its dimensions are approximately 143.1 × 74.8 × 223.3 mm and the device weighs approximately 900 grams without batteries.
View the HIKMICRO HABROK 4K 2.0 HH35L at JVS Outdoor
The HIKMICRO HABROK 4K 2.0 HH35L is available to view and try by appointment at JVS Outdoor. You can also receive personal advice from experienced hunters who can use their practical experience to help you select the right thermal imaging and night vision equipment for your needs.
