Thermal riflescope with 384×288 sensor and integrated 1200 meter laser rangefinder
The RIX LEAP L3R is a compact thermal riflescope with a 384×288 12μm VOx sensor, NETD <20mK thermal sensitivity and a 35mm objective lens. Thanks to the 3.2x to 9.6x optical zoom, 1x to 4x digital zoom and the 1920×1080 AMOLED display, you get a sharp and high-contrast sight picture. Even in challenging conditions such as rain, snow or high humidity.
This thermal riflescope features an integrated laser rangefinder up to 1200 meters, a ballistic calculator and a detection range of up to 1800 meters. This makes the RIX LEAP L3R ideal for hunters looking for a lighter thermal riflescope for medium-range distances. The operation with three large rotary knobs and two buttons is intuitive, even in the dark or while wearing gloves. This riflescope is robustly built, IP67 water-resistant and resistant to heavy recoil up to 1000g / 6000 joules.
Video RIX LEAP L3R
Key features RIX LEAP L3R
384×288 thermal sensor: provides a clear thermal image for observing and identifying game at medium range.
NETD <20mK: high thermal sensitivity for better contrast in rain, snow, fog or high humidity.
35mm objective lens: compact lens with strong performance for hunting near forest edges, fields and mixed terrain.
Detection range up to 1800 meters: suitable for early detection of heat sources at medium to longer distances.
Integrated laser rangefinder up to 1200 meters: measures distances directly through the riflescope without separate accessories.
Built-in ballistic calculator: helps determine the correct aiming point for more accurate shooting.
3.2x to 9.6x optical zoom: smooth magnification while maintaining a clear and usable image.
AMOLED display 1920×1080: provides a high-contrast and comfortable image during observation and aiming.
Wi-Fi and RIX+ app support: suitable for live view, wireless software updates and smartphone connection.
Strong housing with IP67 protection: reliable for use in rain, dust and intensive hunting conditions.
Included accessories RIX LEAP L3R
According to the manual, the RIX LEAP L3R is supplied with the following accessories:
- RIX LEAP L3R thermal riflescope
- Eyecup
- Riflescope rings
- USB Type-C cable
- Battery charger
- 18650 battery
- Lens cloth
- Thermal zeroing target
Key specifications RIX LEAP L3R
| Model | RIX LEAP L3R |
| Resolution and μm | 384×288 12μm |
| Sensor type | VOx uncooled |
| NETD | <20mK |
| Detection range | 1800 meters |
| Rangefinder | Yes, integrated LRF up to 1200 meters |
| Lens diameter | 35mm |
| Field of View | 7.5° × 4.2° |
| Screen type | AMOLED 1920×1080 |
| Battery duration | Up to 4 hours |
| Battery replaceable | Yes, 18650 battery |
| Weight | 1230 grams / 2.7 lb |
| Color Palettes | White hot, black hot, red hot, edge |
| Zoom options | Optical 3.2x to 9.6x, digital 1x to 4x |
| Adjustable contrast | Yes |
| Water-resistance rating | IP67 |
Availability and advice
The RIX LEAP L3R can be viewed and tested by appointment. At JVS-Outdoor, you receive advice from experienced hunters who can help you choose the right thermal riflescope for your hunting situation.
Further manufacturer specifications
Frame rate: 50Hz
Base magnification: 3.2x to 9.6x
Digital zoom: 1x to 4x
Eye relief: 50mm
Diopter adjustment: -5 to +5
Video/photo resolution: 1280×720
Video/photo format: .mp4 / .jpg
Internal memory: 32GB
Laser rangefinder measuring range: 1200 meters / 1312 yards
Measurement accuracy: ±1 meter / ±1.09 yards
Operating temperature: -20°C to +50°C / -4°F to +122°F
Wi-Fi: Yes, support via RIX+ app
External power supply: 5V USB-C
Maximum recoil resistance: 1000g / 6000J
Compatible mount: 30mm rings
Dimensions: 371×89×76mm / 14.2×3.5×3 inch
Battery type: 18650
Reticle precision: 0.35 MOA
Return to Center function: Yes
PIP display: Yes
Photo and video recording: Yes
